ABB CM10/000S0F0/STD Universal PID Process Controller
| Brand: ABB ControlMaster CM10 series |
| Item NO: CM10/000S0F0/STD |
| Effect: Support multi type process signal acquisition |
| Condition: In stock, brand new/Used |
| Warranty: 365 days |
| Payment:T/T 50% deposit, 50% balance |
| www.szcxdcs.com |
+86 15359298293
ABB CM10/000S0F0/STD Universal PID Process Controller
CM10/000S0F0/SDD is an ABB 1/8 DIN panel type universal process PID controller that integrates a color TFT display screen and supports multiple types of process signal acquisition. It can achieve closed-loop control of process parameters such as temperature, pressure, flow rate, and liquid level.
CM10/000S0F0/STD supports PID automatic tuning, switch control, time proportional control, and split range output control; Equipped with multiple alarm outputs, it can be operated locally on the panel or configured through computer software; CM10/000S0F0/STD is used to measure, calculate, and adjust industrial process parameters, output control signals to drive actuators such as valves and heaters, achieve stable process parameters, and complete over limit alarm protection, adapting to various industrial process automation sites.
Parameter Specifications
| Parameter | Specification |
|---|---|
| Model | CM10/000S0F0/STD |
| Form Factor | 1/8 DIN panel mount |
| Display | 2.2″ full‑color TFT LCD |
| Universal Inputs | 1 universal process input, 1 secondary process input |
| Supported Input Types | Thermocouple, RTD, mA, V, mV, Resistance, Frequency, Digital input |
| Primary Outputs | 1 analog/digital output, 1 relay output |
| Power Supply | 100‑240V AC ±10%, 50/60Hz |
| Power Consumption | Max 10W |
| Control Modes | On‑Off, Time‑proportioning, PID, Split‑range output, Auto‑tune |
| Alarm Function | 8 independent process alarms |
| Front Panel Protection | IP66, NEMA 4X |
| Rear Enclosure Protection | IP20 |
| Operating Temperature | 0℃ ~ +55℃ |
| Storage Temperature | -20℃ ~ +70℃ |
| Relative Humidity | 5‑95% RH non‑condensing |
| Dimensions (H×W×D) | 97 × 50 × 121 mm |
| Net Weight | 0.38 kg |
| Certifications | CE, IEC61010‑1, IEC61326‑1 |
| Language | French |
| Communication | No built‑in communication port |
Product features
- Universal multi signal input: compatible with thermocouples, thermistors, analog current and voltage, frequency, digital signals, one instrument can adapt to various process measurements such as temperature, pressure, flow rate, liquid level, etc.
- Color TFT display screen: 2.2-inch color screen, with intuitive display of process values, alarm status, and set values, simple human-computer interaction, and support for custom display interface.
- Rich control algorithms: Built in PID self-tuning function, supports switch control, time ratio, analog PID, and split range output, can quickly complete on-site debugging, reduce parameter tuning workload ABB Group.
- Multi channel independent alarm: 8 independent process alarms, which can be linked with relay outputs to achieve process limit warning and interlock protection.
- High protection panel: The front panel is IP66/NEMA4X protected, dustproof and waterproof, suitable for humid and dusty industrial sites; Rear IP20, installed inside standard cabinet.
- Dual configuration mode: Supports direct parameter setting through the front panel buttons, and can also be configured in batches using PC configuration software for easy batch debugging and parameter backup.
- Security permission management: Supports two-level password protection, distinguishing between basic operations and advanced parameter modifications to prevent accidental modification of key control parameters.
- Modular hardware architecture: basic body, expandable IO options; This model is the basic version and does not come with a communication interface.
