Bently Nevada 9200-01-01-10-00 Dynamic coil speed sensor

Bently Nevada 9200-01-01-10-00 Dynamic coil speed sensor

9200-01-01-10-00 is a Bently Nevada 9200 series Seismoprobe dynamic speed sensor used to measure absolute vibration (shell vibration/tile vibration) of bearing housings and equipment casings. 9200-01-01-10-00 adopts the principle of dynamic coil, which does not require external power supply. It directly outputs a voltage signal proportional to the vibration speed, which is sent to TSI monitoring systems such as 3500 to monitor the vibration amplitude of large rotating equipment bearing shells in real time; When the vibration exceeds the standard, an alarm or interlock is triggered to protect equipment such as turbines, compressors, and fans. 9200-01-01-10-00 is the core sensor for measuring shell vibration in the TSI system for unit status monitoring.

Product features

1. Passive two-wire dynamic coil structure, does not require external power supply, simple installation and wiring, and also supports portable vibration detection.
2. Specifically measure the absolute vibration (tile vibration) of the bearing housing, complementing the axial displacement measurement of the eddy current probe.
3. Not sensitive to impact and pulse excitation, suitable for long-term continuous monitoring of rotating machinery with instantaneous impact conditions.
4.  Integrated sensor structure, corrosion-resistant, can be directly installed on the equipment casing without the need for additional protective casing.
5.  Wide frequency response range, covering the majority of rotating machinery’s frequency and harmonic vibrations, suitable for fault diagnosis and analysis.
6.  The installation thread is 1/2-20 UNF standard thread, suitable for the installation base of most unit tile vibration measurement points.
7.  Output analog voltage signals, which can be directly connected to Bently 3500 vibration monitoring card or paired with 9513 speed displacement converter.
8.  Sturdy metal shell, earthquake resistant, able to withstand harsh working conditions such as high temperature, dust, and oil mist in industrial plants.

Main product range

• Control system (DCS/PLC/CNC): panel controller, HMI and human-machine interface, industrial PC, CPU processor module, communication module, analog/digital I/O module
• Drive and motion control: frequency converter, servo drive, servo motor, power module
• Robot spare parts: key spare parts such as robot control board, axis computer, servo unit, I/O module, etc
• State monitoring and safety system: vibration monitoring system, safety instrumented system (SIS), redundant controller

Application Industry

The products are widely used in various industrial fields such as metallurgy, oil and gas, petrochemicals, electricity, power transmission and distribution, water conservancy, water treatment and environmental protection, coal mining, aluminum industry, glass manufacturing, paper and printing, textile printing and dyeing, machinery manufacturing, electronics manufacturing, automobile manufacturing, plastic machinery, boiler heating, energy, etc.

Bently Nevada 9200-01-01-10-00 Dynamic coil speed sensor

Main brand

————————Shenzhen Changxin Automation Equipment Co Ltd -————————

Products that have been released are welcome for consultation. Due to the wide variety of models, we were unable to upload physical images one by one!

Bently Nevada 9200-01-01-10-00 Dynamic coil speed sensor

Parameter Specifications
