Honeywell ControlEdge HC900 Controller 900U02-0100 Safe Universal IO Module
| Brand: Honeywell |
| Item NO: ControlEdge HC900 900U02-0100 |
| Effect: 6 customizable channels, no need to distinguish between analog input, analog output, digital quantity, temperature acquisition dedicated board |
| Condition: In stock, brand new/Used |
| Warranty: 365 days |
| Payment:T/T 50% deposit, 50% balance |
| www.szcxdcs.com |
+86 15359298293
Honeywell ControlEdge HC900 Controller 900U02-0100 Safe Universal IO Module
900U02-0100 is a SIL2 safety grade universal I/O module that is compatible with the Honeywell ControlEdge HC900 controller. 900U02-0100 integrates 16 customizable channels, without the need to distinguish between analog input, analog output, digital quantity, and temperature acquisition dedicated boards. The module is compatible with various on-site sensors and actuator signals, while meeting the requirements of conventional process control and SIS safety loop use. It comes with HART protocol and can be connected to intelligent transmitters. It is widely used in chemical, energy, water treatment, and boiler combustion management systems.
Core function
- Unified collection of multiple signals
A single module with 16 channels can be independently configured to collect on-site measurement signals such as 4-20mA current, voltage, thermal resistance RTD, thermocouple TC, and switch DI. The on-site physical quantities are converted into digital signals recognizable by the controller to complete the collection of process parameters such as temperature, pressure, liquid level, and flow rat - Control instruction output driver
Support analog AO and digital DO output, receive controller operation instructions, output 4-20mA control regulating valves, output switch signals to control solenoid valves, fans, pumps and other equipment, achieve closed-loop regulation and equipment start stop logic control.
Safety interlock signal processing - Safety interlock signal processing
Equipped with SIL2 safety certification, compatible with ESD emergency shutdown, combustion management BMS, safety instrument circuit, real-time line diagnosis for channel disconnection and short circuit, automatic triggering of safety failure actions for faults, ensuring safe shutdown of the device.
Honeywell ControlEdge HC900 Controller 900U02-0100 Safe Universal IO Module
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | 900U02-0100 |
| Product Type | SIL2 Safety Universal I/O Module |
| Total Channels | 16 configurable independent channels |
| Supported Input Signals | AI 4-20mA, Voltage, RTD, TC, DI discrete signal |
| Supported Output Signals | AO 4-20mA, DO discrete output |
| Safety Level | SIL 2 certified |
| Communication | Built-in HART protocol |
| Isolation Mode | Point-to-point galvanic isolation |
| Hot Swap | Support hot plug & pull without system shutdown |
| A/D Resolution | 16 bit |
| Field Power Supply | 24 VDC |
| Power Consumption | Less than 2 W |
| Mounting Standard | DIN rail mounting |
| Dimension (H × W × D) | 137 × 33.1 × 151.7 mm |
| Net Weight | 0.26 kg |
| Operating Temperature | 0 ℃ ~ +60 ℃ |
| Storage Temperature | -40 ℃ ~ +70 ℃ |
| Humidity | 10% ~ 90% RH, non-condensing |
| Certifications | CE, UL, CSA, ATEX, FM |
| Application Scope | Process control, SIS ESD system, BMS burner management |
