Rexroth VCP05.2DSN-003-NN-PW compact button type industrial operation panel
| Brand: Rexroth |
| Item NO: VCP05.2DSN-003-NN-PW |
| Effect: On site visualization of equipment operation data |
| Condition: In stock, brand new/Used |
| Warranty: 365 days |
| Payment:T/T 50% deposit, 50% balance |
| www.szcxdcs.com |
+86 15359298293
Rexroth VCP05.2DSN-003-NN-PW compact button type industrial operation panel
VCP05.2DSN-003-NN-PW is a compact button type industrial control panel produced by Rexroth in the IndraControl VCP05.2 series. Compatible with the entire motion control platform of Rexroth IndraMotion servo and IndraLogic PLC. VCP05.2DSN-003-NN-NN-PW adopts a 3-inch 5-grayscale FSTN monochrome LCD+fully physical button integrated design, with a compact size and embedded installation in the cabinet. It is designed for easy on-site monitoring and parameter debugging of equipment, suitable for installation in single machine control cabinets and operation boxes with limited space.
Product function
- On site visualization of equipment operation data
The screen displays the servo axis position, speed, pressure, temperature, IO point, production count, and fault alarm codes in real-time. It supports simple curve and status icon display, and can view the overall working conditions of the machine without the need for an upper computer on site. - Equipment start stop and manual operation control
The panel integrates multiple sets of custom function buttons, which can directly perform device start, stop, reset, single axis jog, mode switching and other operations, replacing external button stations to simplify wiring. - On site modification of process parameters and formula calling
Enter speed and limit through physical buttons PID、 Processing formula and other parameters, supporting local storage and retrieval of multiple sets of formulas, meeting the needs of frequent production changes and debugging. - Fault alarm viewing and reset confirmation
The device automatically pops up a pop-up window to prompt fault information, allowing users to browse historical fault records, complete alarm confirmation reset, and quickly locate servo, hydraulic, and electrical fault points. - Multi bus and multi device communication and interaction
Equipped with Ethernet, RS485, RS232 multiple serial ports, it interfaces with external devices such as Rexroth controllers, servo drives, barcode readers, etc. to achieve data interoperability of the entire machine.
Rexroth VCP05.2DSN-003-NN-PW compact button type industrial operation panel
Parameter Specifications
| Item | Specification |
|---|---|
| Full Model | VCP05.2DSN-003-NN-NN-PW |
| Series | IndraControl VCP05.2 Compact Operator Terminal |
| Display Type | 3″ FSTN Monochrome LCD, 5 Gray Shades |
| Display Resolution | 160 × 80 Pixels |
| CPU | RISC ARM9, 200 MHz with RTC Watchdog |
| Flash Memory | 16 MB |
| Application Memory | 3 MB |
| Backlight Service Life | 50,000 Hours Half-Life |
| Operation Keypad | Multi-function Embedded Physical Keys |
| Supply Voltage | 24 V DC SELV, 18 V ~ 30 V DC Tolerance |
| Max Power Consumption | 6 W, 0.3 A @ 24 V DC |
| Protection Class | Front IP65, Rear IP20 |
| Front Panel Material | Natural Anodized Aluminum Plate |
| Housing Material | Galvanized Steel Sheet |
| Communication Interfaces | 1 × 10/100 Ethernet, RS485, Dual RS232, 2 × USB Host |
| Supported Protocols | Rexroth Native Bus, Serial Modbus |
| Operating Temperature | 0 °C ~ +50 °C |
| Storage Temperature | -20 °C ~ +70 °C |
| Ambient Humidity | 5% ~ 85% RH non-condensing |
| Mounting Mode | Cabinet Embedded Panel Mount |
| Overall Dimension | 168 × 120 × 5 mm (Front Bezel) |
| Net Weight | Approx. 0.79 kg |
| PCB Coating | No Conformal Coating (NN Version) |
| Certification | CE, Industrial EMC Compliance |
Product features
- Ultra compact small body
- Physical keyboard operation
- IP65 aluminum alloy front panel
- Multi channel rich industrial communication interface
- Wide voltage stable power supply
- NN Standard Version without Three Anti Coating
- Supporting Rexroth visualization configuration software
- Simple embedded buckle installation
