Rexroth VT-VPCD-1-16/V0/1-P-1 VT-VPCD series digital pump control amplifier board
| Brand: Bosch Rexroth |
| Item NO: VT-VPCD-1-16/V0/1-P-1 |
| Effect: Core closed-loop control cards for injection molding, metallurgy, forging and heavy-duty hydraulic equipment |
| Condition: In stock, brand new/Used |
| Warranty: 365 days |
| Payment:T/T 50% deposit, 50% balance |
| www.szcxdcs.com |
+86 15359298293
VT-VPCD-1-16/V0/1-P-1 VT-VPCD series digital pump control amplifier board
Rexroth VT-VPCD-1-16/V0/1-P-1 is a Bosch Rexroth VT-VPCD series digital pump control amplifier board. Compatible with A4VS (HS4 control) and A2V (EO4 control) variable piston pumps, it is the core closed-loop control card for injection molding, metallurgy, and forging heavy-duty hydraulic equipment;
Core function
- Fully closed-loop precise control of plunger pump
Real time collection of pump tilt angle and system inlet and outlet pressure feedback, completing triple closed-loop calculation of swing angle, constant pressure stabilization, and power limitation, outputting driving current to control the pump proportional solenoid, and continuously adjusting the pump output flow rate and pressure. - Quick switching of multiple sets of operating parameters
Equipped with 16 digital input channels, it can store multiple sets of pressure, slope, and power limit parameter groups, and switch different process curves such as no-load, pressure holding, and processing with one click through DI signals. - Industrial bus networking communication
Equipped with RS232 local debugging port and PROFIBUS-DP bus interface, it can interact with the upper PLC to operate parameters and fault codes. A single system can have up to 32 boards synchronously linked with multiple pump units. - Slope buffering and leakage compensation
Built in pressure and swing angle command slope time setting to avoid pressure impact; Equipped with a leakage compensation algorithm, it can maintain stable control accuracy during long-term operation.
VT-VPCD-1-16/V0/1-P-1 VT-VPCD series digital pump control amplifier board
Parameter Specifications
| Spec Item | Parameter |
|---|---|
| Manufacturer | Bosch Rexroth Indramat |
| Full Part Number | VT-VPCD-1-16/V0/1-P-1 |
| Rexroth Material No. | R901089559 |
| Product Type | Digital Closed-loop Control Card for Variable Displacement Pumps |
| Applicable Pumps | A4VS (HS4 control), A2V (EO4 control) |
| Form Factor | Eurocard 100 mm × 160 mm plug-in rack mount |
| Supply Voltage | 24 VDC (21 ~ 33.6 VDC operating range) |
| Max Power Consumption | 3.5 A |
| Digital Input Channels | 16 DI for parameter group selection |
| Communication Interfaces | RS232 local debug, PROFIBUS-DP (P suffix) |
| Control Scan Cycle | 5 ms |
| Solenoid Nominal Resistance | 2 Ω @ 20℃ |
| Connector Standard | 64-pin DIN 41612 edge connector |
| Conformal Coating | Yes |
| Operating Temperature | 0 ℃ ~ +50 ℃ |
| Storage Temperature | -20 ℃ ~ +70 ℃ |
| Humidity Range | 5% ~ 90% Non-condensing, non-condensing |
| Net Weight | 0.20 kg |
| Max Network Capacity | Up to 32 boards master-slave network |
| Configuration Software | BODAC |
| Production Status | Discontinued, EOL since 2023 |
| Recommended Replacement | HCD series digital pump control electronics |
