B&R 8V1090.001-2 4kW single axis servo drive

B&R 8V1090.001-2 4kW single axis servo drive

8V1090.001-2 belongs to the B&R ACOPOS series single axis servo drive, with a rated power of 4kW and a circuit board with coating protection version.

The main function of 8V1090.001-2 is to receive instructions from the B&R PLC/motion controller, achieve closed-loop control of torque, speed, and position of servo motors, and complete high-precision positioning, synchronous motion, electronic cam and other process actions. 8V1090.001-2 comes with a built-in input filter and built-in braking resistor, supporting plug-in communication modules to expand buses such as POWERLINK and CANopen. It is widely integrated into complete automation equipment to achieve precise motion control of single axis servo. At the same time, it has electronic safety restart interlock function to enhance the safety level of equipment operation.

Product features

1. The circuit board is designed with coating protection, which can withstand dust, moisture, and slightly corrosive gases compared to the ordinary version, and is suitable for cabinet environments with relatively harsh working conditions.
2.  Integrate incoming filter and built-in braking resistor, reduce external accessories, simplify control cabinet wiring, and lower project costs.
3. Modular plug-in expansion design, 4 expansion slots, can be installed with POWERLINK, CANopen, various encoder interface modules as needed, flexible communication and feedback selection.
4. Supports three control modes: torque, speed, and position, suitable for complex motion processes such as electronic cam, master-slave synchronization, and flying shear.
5. Built in electronic safety restart interlock function, which can prevent accidental automatic restart and meet mechanical equipment safety regulations
6.  The switch frequency supports three adjustable levels of 5/10/20kHz, suitable for different motors, with smooth low-speed operation and excellent dynamic response performance.
7.  Rich fault self diagnosis function, which can monitor faults such as overcurrent, overvoltage, undervoltage, overtemperature, motor disconnection, etc., and quickly locate problems
8.  Fully plug-in terminal blocks, easy to disassemble and maintain, convenient for on-site spare parts replacement, and shorten equipment downtime.
9. Perfectly compatible with the B&R X20 and APROL automation platforms, and compatible with B&R servo motors for plug and play use.

Main product range

• Control system (DCS/PLC/CNC): panel controller, HMI and human-machine interface, industrial PC, CPU processor module, communication module, analog/digital I/O module
• Drive and motion control: frequency converter, servo drive, servo motor, power module
• Robot spare parts: key spare parts such as robot control board, axis computer, servo unit, I/O module, etc
• State monitoring and safety system: vibration monitoring system, safety instrumented system (SIS), redundant controller

Application Industry

The products are widely used in various industrial fields such as metallurgy, oil and gas, petrochemicals, electricity, power transmission and distribution, water conservancy, water treatment and environmental protection, coal mining, aluminum industry, glass manufacturing, paper and printing, textile printing and dyeing, machinery manufacturing, electronics manufacturing, automobile manufacturing, plastic machinery, boiler heating, energy, etc.

B&R 8V1090.001-2 4kW single axis servo drive

Main brand

————————Shenzhen Changxin Automation Equipment Co Ltd -————————

Products that have been released are welcome for consultation. Due to the wide variety of models, we were unable to upload physical images one by one!

B&R 8V1090.001-2 4kW single axis servo drive

Parameter Specifications
