Eaton XP-503-15-A10-A00-1B 15.6-inch industrial control all-in-one computer

Eaton XP-503-15-A10-A00-1B 15.6-inch industrial control all-in-one computer

Eaton XP-503-15-A10-A00-1B belongs to the Eaton XP500 series 15.6-inch industrial integrated panel PC (industrial control integrated machine HMI), pre installed with Windows Embedded Standard 7 operating system, and equipped with PCT capacitive multi touch screen. XP-503-15-A10-A00-1B is not only an industrial human-machine operation panel, but also has industrial computer computing capabilities, used for on-site process screen display, equipment parameter monitoring, manual operation, alarm viewing, and historical data recording; It can run SCADA and configuration programs, communicate with PLC, drivers, and instruments through network/serial ports, and achieve local monitoring of automated production lines. It comes with Galileo configuration and operation authorization.

Product features

1. Fanless all solid state hardware design, no rotating parts, higher reliability in dust and vibration environments, reducing the probability of equipment failure.
2. 15.6-inch widescreen capacitive multi touch, supporting gesture zooming and sliding operations, scratch resistant reinforced glass panel, suitable for frequent operation scenarios in the workshop.
3. Dual independent Gigabit Ethernet ports can be used for network isolation, distinguishing between control networks and IT networks, and enhancing industrial network security.
4. Built in 32GB solid-state drive+CFast pluggable storage card, used for storing engineering programs, historical alarms, and production records.
5. Equipped with RS232/RS485 serial ports, it is compatible with various old PLCs, instruments, and frequency converters, allowing for flexible integration between new and old devices.
6. Pre installed Windows embedded system with Protect Mode protection mode to prevent unauthorized modification of the system and prevent accidental power outages from damaging the system.
7. Die cast aluminum thin body, front panel IP65 protection, dust-proof and splash proof, suitable for embedded installation in control cabinets.
8. Comes with Galileo configuration and operation authorization, without the need to purchase additional operation licenses, directly loads the Galileo project screen.
9. Rich interface expansion, supporting USB external keyboard and mouse, USB flash drive, convenient for project uploading, downloading, and on-site debugging.

Main product range

• Control system (DCS/PLC/CNC): panel controller, HMI and human-machine interface, industrial PC, CPU processor module, communication module, analog/digital I/O module
• Drive and motion control: frequency converter, servo drive, servo motor, power module
• Robot spare parts: key spare parts such as robot control board, axis computer, servo unit, I/O module, etc
• State monitoring and safety system: vibration monitoring system, safety instrumented system (SIS), redundant controller

Application Industry

The products are widely used in various industrial fields such as metallurgy, oil and gas, petrochemicals, electricity, power transmission and distribution, water conservancy, water treatment and environmental protection, coal mining, aluminum industry, glass manufacturing, paper and printing, textile printing and dyeing, machinery manufacturing, electronics manufacturing, automobile manufacturing, plastic machinery, boiler heating, energy, etc.

Eaton XP-503-15-A10-A00-1B 15.6-inch industrial control all-in-one computer

Main brand

————————Shenzhen Changxin Automation Equipment Co Ltd -————————

Products that have been released are welcome for consultation. Due to the wide variety of models, we were unable to upload physical images one by one!

Parameter Specifications
