Allen-Bradley 1797-PS2N2 intrinsically safe explosion-proof power module
| Brand: Allen‑Bradley （Rockwell） |
| Item NO: 1797-PS2N2 |
| Effect: FLEX Ex series intrinsic safety explosion-proof power module |
| Condition: In stock, brand new/Used |
| Warranty: 365 days |
| Payment:T/T 50% deposit, 50% balance |
| www.szcxdcs.com |
+86 15359298293
Allen-Bradley 1797-PS2N2 intrinsically safe explosion-proof power module
1797-PS2N2 is a Rockwell Allen-Bradley FLEX Ex series intrinsic safety explosion-proof power module, belonging to the core power supply unit of FLEX Ex intrinsic safety I/O system. 1797-PS2N2 receives 24VDC DC input, built-in energy limiting circuit, and outputs 4 independent intrinsic safety power supplies, providing safe power supply for hazardous area FLEX Ex series I/O cards, on-site intrinsic safety transmitters, valves and other instruments. 1797-PS2N2 provides energy current limiting isolation for the input power supply in the safe area, limiting the maximum electrical energy sent to the explosion-proof hazardous area to prevent circuit sparks from igniting explosive media. At the same time, it provides stable power supply for the entire intrinsically safe I/O rack, ensuring the signal acquisition and output of the PLC control system in the explosion-proof area. It is an essential hardware for the FLEX Ex system in chemical explosion-proof scenarios.
Parameter Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Allen‑Bradley (Rockwell Automation) |
| Model | 1797-PS2N2 |
| Product Type | Intrinsically Safe Power Supply (FLEX Ex) |
| System Series | 1797 FLEX Ex I/O System |
| Input Voltage Range | 19 ~ 32 VDC |
| Rated Input Current | 3.1 A |
| Input Ripple | Max 5% AC ripple |
| Output Channels | 4 independent IS channels |
| Power per Channel | 8.5 W |
| Output Open Circuit Voltage Uo | <9.5 V |
| Max Output Current Io | <1 A |
| Entity Capacitance Co(IIC) | <500 nF |
| Entity Inductance Lo(IIC) | <8 μH |
| Galvanic Isolation | Input and IS output galvanically isolated |
| Enclosure Type | Explosion-proof housing |
| Conduit Entry | 1 inch NPT |
| Enclosure Rating | IP66 / NEMA 7B |
| Hazardous Area Certification | Class I Div.1 Groups A,B,C,D; Class II Div.1 Groups E,F,G; T4 |
| Operating Temperature | -20 ℃ ~ +70 ℃ |
| Storage Temperature | -40 ℃ ~ +85 ℃ |
| Relative Humidity | 5% ~ 95% non-condensing |
| Diagnostic | Power status monitoring, output fault detection |
| Shock Resistance | IEC 60068-2-27 |
| Vibration Resistance | IEC 60068-2-6 |
| Dimension (W×H×D) | 140 mm × 174 mm × 174 mm |
| Net Weight | 7.3 kg |
| Certification | UL, CSA, FM, ATEX |
