Honeywell CC-GAIX11 8-channel analog input module

Honeywell CC-GAIX11 8-channel analog input module

CC-GAIX11 is an 8-channel analog input module of Honeywell’s Expert C200 system, which belongs to the process control system DCS IO card. The CC-GAIX11 module collects 4-20mA analog signals output by field transmitters, converts continuous industrial process analog signals into digital signals, and transmits them to the C200 controller. It can connect various on-site sensor signals such as pressure, temperature, liquid level, and flow rate, complete process variable acquisition, signal filtering, and range conversion, and provide measurement data for process control, parameter monitoring, and alarm logic. It is widely used in DCS control systems for chemical, power, and other process industries.

Product features

1. 8-channel 4-20mA analog acquisition, with electrical isolation between channels to prevent mutual interference between different circuits.
2. 16 bit high-precision analog-to-digital conversion, high measurement accuracy, can stably collect process signals from various transmitters.
3. Built in comprehensive channel self diagnosis, capable of detecting wire breakage, over range, module faults, and alerting through status indicator lights.
4. Support signal software filtering to suppress high-frequency noise on site and ensure stable data acquisition.
5. Modular design, directly installed on the C200 IO rack, supports hot swapping, and maintenance and replacement do not affect the operation of other circuits.
6. Compatible with the Expert C200 controller, the backplane bus transmits and collects data at high speed, and the response speed meets the requirements of continuous process control.
7. Industrial reinforced PCB board with moisture-proof protective coating, suitable for dust and humid environments in power plants and chemical control cabinets.
8. Support software range configuration, and set engineering units, upper and lower limits in the system software to adapt to different sensor ranges.
